Tesoo Ultra Wide Angle Lens

Tesoo ultra wide angle lens, also known as super wide angle lens or extreme wide angle lens, can show a considerable range of clarity and helps to enhance the appeal of the picture. The sensor size of ultra wide camera lens is 1/2.7'' to 1/4''. TTL: 13-17.75mm. EFL: 0.83-2.20mm. F.NO: 1.8/2.0/2.2/2.4. MBFL: 1.69-2.63mm. Get ultra wide lens price now! We also have non-fisheye lens with wide angle, contact us if you want to learn more details!

Buy Tesoo Ultra Wide Angle Lens   >

Sliding

02

Specifications of Tesoo Ultra Wide Angle Lens


Ultra Wide Lens
Super Wide Angle Lens
Ultra Wide Camera Lens
Extreme Wide Angle Lens
Wide Angle M12 Lens
PART No.TS-4013T-A00
TTL14.11mm
EFL0.83mm
F/NO2.0
MBFL1.69mm
SENSOR SIZE1/4''1/3''
FOVFOV
(D)195°195°
(H)195°195°
(V)158°190°
DISTORTION(F-θ)＜30%＜30%
MAX IMAGE CIRCLEφ3.68mm
MountM12*0.5
CONSTRUCTION2G4P+Plastic
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*12.42
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


2.8mm Wide Angle Lens
Ultra Wide Angle Lens
Ultra Wide Lens
Super Wide Angle Lens
Ultra Wide Camera Lens
PART No.TS-4013T-A01
TTL14.11mm
EFL0.83mm
F/NO2.0
MBFL1.69mm
SENSOR SIZE1/4''1/3''
FOVFOV
(D)220°220°
(H)210°220°
(V)158°190°
DISTORTION(F-θ)＜27%＜27%
MAX IMAGE CIRCLEφ4.0mm
MountM12*0.5
CONSTRUCTION2G4P+Plastic
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*12.42
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Extreme Wide Angle Lens
Wide Angle M12 Lens
2.8mm Wide Angle Lens
Ultra Wide Angle Lens
Ultra Wide Lens
PART No.TS-3013U-A00
TTL13mm
EFL1.40mm
F/NO1.8
MBFL2.10mm
SENSOR SIZE1/3''1/2.7''
FOVFOV
(D)210°210°
(H)210°210°
(V)130°150°
DISTORTION(F-θ)＜-20%＜-20%
MAX IMAGE CIRCLEφ4.40mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*10.9
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Super Wide Angle Lens
Ultra Wide Camera Lens
Extreme Wide Angle Lens
Wide Angle M12 Lens
2.8mm Wide Angle Lens
PART No.TS-2913U-A00
TTL13.2mm
EFL1.35mm
F/NO2.0
MBFL2.20mm
SENSOR SIZE1/2.9''1/2.7''
FOVFOV
(D)215°215°
(H)215°215°
(V)130°140°
DISTORTION(F-θ)＜-20%＜-20%
MAX IMAGE CIRCLEφ4.70mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*11
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Extreme Wide Angle Lens
Super Wide Angle Lens
Ultra Wide Camera Lens
Wide Angle M12 Lens
PART No.TS-2818S-A02
TTL16.64mm
EFL2.20mm
F/NO2.0
MBFL2.16mm
SENSOR SIZE1/2.7''1/2.3''
FOVFOV
(D)188°200°
(H)160°176°
(V)85°130°
DISTORTION(F-θ)＜-9.8%＜-11%
MAX IMAGE CIRCLEφ6.90mm
MountM12*0.5
CONSTRUCTIONAll Glass+Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*14.48
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Ultra Wide Angle Lens
Ultra Wide Lens
Super Wide Angle Lens
Ultra Wide Camera Lens
Extreme Wide Angle Lens
PART No.TS-2816T-A01
TTL15.89mm
EFL1.83mm
F/NO2.4
MBFL2.63mm
SENSOR SIZE1/2.7''1/2.3''
FOVFOV
(D)212°220°
(H)180°198°
(V)102°150°
DISTORTION(F-θ)＜-0.6%＜-1%
MAX IMAGE CIRCLEφ6.80mm
MountM12*0.5
CONSTRUCTIONAll Glass+Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*13.26
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Extreme Wide Angle Lens
Ultra Wide Angle Lens
Wide Angle M12 Lens
2.8mm Wide Angle Lens
PART No.TS-2015T-A00
TTL14.8mm
EFL1.70mm
F/NO2.0
MBFL2.10mm
SENSOR SIZE1/2.7''1/2.3''
FOVFOV
(D)200°200°
(H)190°200°
(V)100°150°
DISTORTION(F-θ)＜-20%＜-20%
MAX IMAGE CIRCLEφ5.90mm
MountM12*0.5
CONSTRUCTION2G4P+Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ14/16*13.26
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


Wide Angle M12 Lens
2.8mm Wide Angle Lens
Ultra Wide Angle Lens
Ultra Wide Lens
Super Wide Angle Lens
PART No.TS-2918X-A18
TTL17.75mm
EFL1.26mm
F/NO2.2
MBFL1.84mm
SENSOR SIZE1/2.7''1/2.3''
FOVFOV
(D)240°240°
(H)240°240°
(V)150°222°
DISTORTION(F-θ)＜-7%＜-7%
MAX IMAGE CIRCLEφ4.90mm
MountM12*0.5
CONSTRUCTIONAll Glass+Metal
IP RatingIPX7 or IP69K
DIAMENSIONSφ18*15.91
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃
