Tesoo 6mm Lens Field Of View

Tesoo 6mm lens field of view not only extends the focal length of a camera but also amplifies its angle of field. As one of the most professional CCTV lens suppliers, we provide high-quality 6mm CCTV lens, which sensor size is 1/1.7'' to 1/3''. TTL:  15.69- 22.5mm. EFL: 5.60-6mm. F.NO: 1.6/2.2/2.4/2.5/2.6. MBFL: 3.7-6.24mm. Get more information about the 6mm CCTV lens and a 6mm CCTV lens price now!

Buy Tesoo 6mm Lens Field Of View   >

Sliding

02

Tesoo 6mm Lens Field Of View Specifications


6mm Lens
6mm Lens Field of View
6mm Camera Lens
6mm Cctv Lens
6mm Lens
PART No.6mm CCTV Lens TS-2716G-A10
TTL15.69mm
EFL5.60mm
F/NOF2.6
MBFL6.24mm
SENSOR  SIZE1/2.7''
FOV
(D)69°
(H)61°
(V)34°
MAX IMAGE CIRCLEφ6.80mm
MountM7*0.35
CONSTRUCTIONAll Glass+Metal
DIAMENSIONSφ8.1*9.45
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


6mm Cctv Lens
6mm Lens Field of View
6mm Lens
6mm Camera Lens
6mm Cctv Lens
PART No.6mm CCTV Lens TS-2722G-C00
TTL21.75mm
EFL5.92mm
F/NOF2.5
MBFL3.7mm
SENSOR  SIZE1/2.7''
FOV
(D)71°
(H)61°
(V)32°
MAX IMAGE CIRCLEφ7.20mm
MountM12*0.5
CONSTRUCTION1G3P
DIAMENSIONSφ14*18.8
Operating temp.-10~ +70℃
Storage temp.15~ +75℃


6mm Camera Lens
6mm Lens
6mm Lens Field of View
6mm Cctv Lens
PART No.6mm CCTV Lens TS-2723G-A00
TTL22.5mm
EFL6mm
F/NOF1.6
MBFL3.7mm
SENSOR  SIZE1/2.7''
FOV
(D)65°
(H)57°
(V)31°
MAX IMAGE CIRCLEφ6.8mm
MountM12*0.5
CONSTRUCTION1G3P
DIAMENSIONSφ14*18.8
Operating temp.-10~ +70℃
Storage temp.15~ +75℃


6mm Camera Lens
6mm Cctv Lens
6mm Lens
6mm Lens Field of View
6mm Camera Lens
PART No.6mm CCTV Lens TS-3022F-A00
TTL21.9mm
EFL6mm
F/NOF2.2
MBFL3.7mm
SENSOR  SIZE1/3''
FOV
(D)60°
(H)48°
(V)34°
MAX IMAGE CIRCLEφ6.0mm
MountM12*0.5
CONSTRUCTION4G
DIAMENSIONSφ14*18.8
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


6mm Camera Lens
6mm Cctv Lens
6mm Lens
6mm Lens Field of View
PART No.6mm CCTV Lens TS-1817I-A00
TTL16.73mm
EFL5.60mm
F/NOF2.4
MBFL5.06mm
SENSOR  SIZE1/1.7''(16:9)
FOV
(D)90°
(H)79°
(V)45°
MAX IMAGE CIRCLEφ9.7mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*11.67
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


6mm Lens Field of View
6mm Camera Lens
6mm Cctv Lens
6mm Lens
6mm Lens Field of View
PART No.6mm CCTV Lens TS-2022I-A00
TTL22.11mm
EFL5.60mm
F/NOF2.2
MBFL5.06mm
SENSOR  SIZE1/2''(16:9)
FOV
(D)92°
(H)80°
(V)46°
MAX IMAGE CIRCLEφ8.70mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*17.05
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃
