Tesoo M12 Camera Lens

Tesoo m12 camera mount can increase the C port so that you can connect the M12 interface camera to the driving recorder. The sensor size of m12 camera mount is 1/1.8''and 1/3''. TTL: 15.02-25.3mm. EFL: 2.90-16mm. F.NO: 1.6/1.8/2.0/2.2/2.4/2.8/4.0/4.8. MBFL: 2.21-6.55mm. Get m12 camera mount price now!

Buy Tesoo M12 Camera Lens   >

Sliding

02

Specifications of Tesoo M12 Camera Lens


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2721O-A00
TTL21.15mm
EFL2.90mm
F/NO2.2
MBFL5.30mm
SENSOR SIZE1/3''1/2.7''
FOVFOV
(D)132°148°
(H)116°122°
(V)60°64°
TV-DISTORTION<-22%<-30%
MAX IMAGE CIRCLEφ6.90mm
MountM12*0.5
CONSTRUCTION2G3P+Plastic
DIAMENSIONSφ14*15.85
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2723N-B00
TTL22.2mm
EFL3.20mm
F/NO1.6
MBFL5.35mm
SENSOR SIZE1/3''1/2.7''
FOVFOV
(D)120°134°
(H)103°112°
(V)55°59°
TV-DISTORTION<-16%<-19%
MAX IMAGE CIRCLEφ7.0mm
MountM12*0.5
CONSTRUCTION4E+Plastic
DIAMENSIONSφ14*16.85
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2316Q-A00
TTL15.89mm
EFL2.95mm
F/NO2.0
MBFL2.88mm
SENSOR SIZE1/2.5''1/2.3''
FOVFOV
(D)143°168°
(H)125°126°
(V)69°92°
TV-DISTORTION<-33%<-40%
MAX IMAGE CIRCLEφ8.20mm
MountM12*0.5
CONSTRUCTION4G3P+Metal
DIAMENSIONSφ14*13.01
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
PART No.TS-2323O-A17
TTL23mm
EFL3.20mm
F/NO1.8
MBFL5.91mm
SENSOR SIZE1/2.5''1/2.3''
FOVFOV
(D)136°152°
(H)116°117°
(V)65°86°
TV-DISTORTION<-25%<-35%
MAX IMAGE CIRCLEφ8.20mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ17*17.09
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2316M-A00
TTL15.91mm
EFL3.65mm
F/NO2.0
MBFL3.68mm
SENSOR SIZE1/2.5''1/2.3''
FOVFOV
(D)132°148°
(H)110°112°
(V)58°76°
TV-DISTORTION<-28%<-35%
MAX IMAGE CIRCLEφ8.20mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*12.23
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-1823N-A00
TTL23mm
EFL4.0mm
F/NO2.8
MBFL5.93mm
SENSOR SIZE1/2.3''1/1.8''
FOVFOV
(D)118°135°
(H)93°110°
(V)69°73°
TV-DISTORTION<-20%<-25%
MAX IMAGE CIRCLEφ10.2mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*17.07
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
PART No.TS-1825I-A20
TTL25.3mm
EFL4.20mm
F/NO2.8
MBFL2.21mm
SENSOR SIZE1/2.3''1/1.8''
FOVFOV
(D)78°93°
(H)68°81°
(V)55°65°
TV-DISTORTION<-0.3%<-0.5%
MAX IMAGE CIRCLEφ9.60mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ20*23.09
Operating temp.-20 ~ +80℃
Storage temp.-40 ~ +90℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
PART No.TS-2322H-A00
TTL22mm
EFL4.28mm
F/NO2.2
MBFL2.55mm
SENSOR SIZE1/2.5''1/2.3''
FOVFOV
(D)78°82°
(H)66°69°
(V)36°55°
TV-DISTORTION<-1%<-1.5%
MAX IMAGE CIRCLEφ8.30mm
MountM12*0.5
CONSTRUCTION4G2P+Metal
DIAMENSIONSφ14*19.45
Operating temp.-20 ~ +75℃
Storage temp.-25 ~ +80℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
PART No.TS-1817I-A00
TTL16.73mm
EFL5.60mm
F/NO2.4
MBFL5.06mm
SENSOR SIZE1/2.3''1/1.8''
FOVFOV
(D)82°93°
(H)62°78°
(V)44°50°
TV-DISTORTION<-10%<-12%
MAX IMAGE CIRCLEφ9.70mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*11.67
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2721F-A00
TTL21.43mm
EFL6.50mm
F/NO2.0
MBFL6.55mm
SENSOR SIZE1/2.5''1/2.3''
FOVFOV
(D)62°64°
(H)53°51°
(V)31°40°
TV-DISTORTION<-10%<-12%
MAX IMAGE CIRCLEφ8.80mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*15.45
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
PART No.TS-2015E-A00
TTL15.02mm
EFL10.50mm
F/NO4.0
MBFL5.06mm
SENSOR SIZE1/2.5''1/2''
FOVFOV
(D)38°46°
(H)33°40°
(V)19°28°
TV-DISTORTION<-1%<-1.4%
MAX IMAGE CIRCLEφ9.60mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*17.05
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
M12 Lens Focal Length
M12 Camera Mount
PART No.TS-2716C-A00
TTL16mm
EFL16mm
F/NO4.8
MBFL2.89mm
SENSOR SIZE1/3''1/2.5''
FOVFOV
(D)22°27°
(H)20°23°
(V)11°13°
TV-DISTORTION<-0.1%<-0.5%
MAX IMAGE CIRCLEφ7.60mm
MountM12*0.5
CONSTRUCTIONAll glass+Metal
DIAMENSIONSφ14*13.11
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃
