Tesoo Scanning Low Distortion Lens

Tesoo scanning lens can reduce the degree of perspective deformation. The sensor size of scanning lens is 1/2'' to 1/3''. TTL: 7.49-22.3mm. EFL: 1.65-16mm. F.NO: 2.0/2.2/2.6/4.0/4.8/6.0. MBFL: 1.48-6.30mm. Get scanning lens price now! Tesoo also provides other kinds of low distortion lens such as wide angle lens no distortion and low distortion lens of different sizes.

Buy Tesoo Scanning Low Distortion Lens   >

Sliding

02

Specifications of Tesoo Scanning Low Distortion Lens


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2015E-A00
TTL15.02mm
EFL10.50mm
F/NO4.0
MBFL5.06mm
SENSOR  SIZE1/2.5''1/2''
FOVFOV
(D)38°46°
(H)33°40°
(V)19°28°
TV-DISTORTION<-1%<-1.4%
MAX IMAGE CIRCLEφ9.60mm
MountM12*0.5
CONSTRUCTIONAll Glass +Metal
DIAMENSIONSφ14*17.05
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2019D-A00
TTL18.72mm
EFL10mm
F/NO6.0
MBFL6.30mm
SENSOR  SIZE1/2''1/2.5''
FOVFOV
(D)42°34°
(H)36°30°
(V)25°18°
TV-DISTORTION<-0.8%<-0.6%
MAX IMAGE CIRCLEφ8.5mm
MountM12*0.5
CONSTRUCTION6E
DIAMENSIONSφ14*12.4
Operating temp.-20 ~ +70℃
Storage temp.-40 ~ +80℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2716C-A00
TTL16mm
EFL16mm
F/NO4.8
MBFL2.89mm
SENSOR  SIZE1/3''1/2.5''
FOVFOV
(D)22°27°
(H)20°23°
(V)11°13°
TV-DISTORTION<-0.1%<-0.5%
MAX IMAGE CIRCLEφ7.60mm
MountM12*0.5
CONSTRUCTIONAll glass+Metal
DIAMENSIONSφ14*13.11
Operating temp.-40 ~ +85℃
Storage temp.-40 ~ +90℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2722L-B00
TTL22.3mm
EFL1.65mm
F/NO2.0
MBFL5.2mm
SENSOR  SIZE1/2.8''1/2.7''
FOVFOV
(D)118°120°
(H)110°115°
(V)84°85°
TV-DISTORTION<-1%<-1.5%
MAX IMAGE CIRCLEφ8.30mm
MountM12*0.5
Resolution4K/8MP
DIAMENSIONSφ14*17.1
Operating temp.-20 ~ +70℃
Storage temp.-40 ~ +80℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2709G-A08
TTL8.47mm
EFL4.60mm
F/NO2.6
MBFL1.48mm
SENSOR  SIZE1/3''1/2.7''
FOVFOV
(D)68°72°
(H)59°66°
(V)38°39°
TV-DISTORTION<-1.5%<-2%
MAX IMAGE CIRCLEφ6.85mm
MountM9*0.35
CONSTRUCTION3G1MG+Metal
DIAMENSIONSφ9*6.99
Operating temp.-30 ~ +80℃
Storage temp.-40 ~ +85℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2508H-A09
TTL7.49mm
EFL4.80mm
F/NO2.6
MBFL1.74mm
SENSOR  SIZE1/3''1/2.7''
FOVFOV
(D)72°77°
(H)62°67°
(V)36°39°
TV-DISTORTION<-1%<-1%
MAX IMAGE CIRCLEφ8.2mm
MountM9*0.35
CONSTRUCTION2G2P +Metal
DIAMENSIONSφ9*5.75
Operating temp.-20 ~ +70℃
Storage temp.-40 ~ +80℃


Scanning Lens
Scanning Lens
Scanning Lens
Scanning Lens
PART No.TS-2322H-A00
TTL22mm
EFL4.28mm
F/NO2.2
MBFL2.55mm
SENSOR  SIZE1/2.5''1/2.3''
FOVFOV
(D)78°82°
(H)66°69°
(V)36°55°
TV-DISTORTION<-1%<-1.5%
MAX IMAGE CIRCLEφ8.30mm
MountM12*0.5
CONSTRUCTION4G2P+Metal
DIAMENSIONSφ14*19.45
Operating temp.-20 ~ +70℃
Storage temp.-40 ~ +90℃
